EV Series Horizontal View Liquid Low Meter

The flow meter construction is made of high strength engineering plastics (PC Polycarbonate or polysulphone). Which is high temperature resistant and corrosion-proof. Allows multiple locations of installation. It bears high pressure, l i.e. Working pressure 1.0mpa; Working Pressure: ≤1.0Mpa Temperature: PC:0-80C PSU:0-120C Accuracy: t 6%

Product Description

■Quick Details

Place of Origin

Zhejiang China

Float material

SS, ABS, PVC

Connection

Male/Female Thread, Tri-clamp

Model NO.

EV Series

Diameter

DN15mm-25mm

Material

PC, PSU

Medium

Water, Liquid, Air, Gas

Customized Support

OEM, ODM, OBM

Max Temp.

100℃

Accuracy

±4%

Brand Name

ZYIA

Working Pressure

≤ 1 Mpa



Introduce

EV - Series construction is made of high strength engineering plastics(PC Polycarbonate or polysulphone).

Which is high temperature resistant and corrosion - proof.allows multiple locations of installation.It bears high pressure.

I i.e.working pressure 1.0mpa;Working Pressure :≤1.0Mpa Temperature:PC:0-80℃ PSU:0-120℃ Accuracy ± 6%.



■Product Features

1) Available in 1/2 to 2 inch ports

2) Offered in a wide variety of fitting styles

3) EV to install in any position

4) No special piping or flow straighteners needed,No electrical connections

5) Direct reading indication


■Technical Parameters of EV Series Tube Type Flow Meter

Model

Range

Thread

Material

Water 20℃

Air 101325pa20℃

GPM

LPM

GPM

LPS

EV

15

20

25

0.5-5

1-7

1-10

1-16

3-18

4-28

2-20

4-26

4-35

5-60

15-65

20-100

80-320

160-480

240-720

320-1100

5-20

10-30

15-45

20-70

1/2"NPT、BSPT、BSP(M、F)

3/4"NPT、 BSPT、BSP(M、F)

1"NPT、BSPT、BSP(M、F)

BRASS

SS

PP

PVC

EV

40

50

3-25

5-50

8-80

10-100

12-90

20-200

30-280

40-380

250-1500

350-2200

450-4500

15-95

20-140

25-275

11/2"NPT、 BSPT、BSP (F)

2"NPT、BSPT、BSP (F)
